Conductive & Thermal Insulation Aluminum Foil Tape Series

  • Description
  • Feature
  • Application
  • Specification

High-performance aluminum foil tape series engineered with soft aluminum foil backing and strong acrylic pressure-sensitive adhesive. Offers exceptional thermal insulation, moisture resistance, electrical conductivity, and strong surface adhesion. Widely used across HVAC ductwork sealing, kitchen range hood piping, refrigeration equipment, and aerospace maintenance.

  • Thermal Insulation & Moisture Sealing: Effectively seals joints to prevent air leakage, moisture penetration, and thermal dissipation.

  • Electrical & Thermal Conductivity: Soft aluminum foil carrier provides excellent conductive and heat-reflective properties.

  • Strong Adhesion Performance: Formulated with high-tack adhesive that grips firmly onto metal, glass, and duct surfaces.

  • High & Low Temperature Resistance: Designed to withstand demanding temperature fluctuations in HVAC and refrigeration systems.

  • AL0204: Central AC ducting in buildings, kitchen exhaust pipes, refrigerator tubing, and water heater pipe joint sealing.

  • AL0212: Electronic appliance wiring joint sealing and maintenance/repair of aircraft aerospace components.

  • AL0215 (A0215): Vapor-tight sealing for glass panel air ducts, galvanized iron sheet ductwork systems, and aluminum foil surface seams.

Product Model Backing Material Peel Strength (N/25mm) Initial Tack (#) Holding Power (h)
AL0204-BE/DJ/EJ Aluminum Foil ≥ 7 ≥ 14 ≥ 7
AL0212-BE/DJ/EJ Aluminum Foil ≥ 8 ≥ 14 ≥ 7
AL0215-BE/DJ/EJ (A0215) Aluminum Foil ≥ 8 ≥ 8 ≥ 24
